AD9

  • AERO
  • CARBON
  • DURA-ACE Di2
  • POWER METER
  • RACING
  • ROAD

WorldTour championship aerodynamics, engineered to stay ahead.

$7,999 Free Ground Shipping

  • "Represents a watershed moment" - Cycling News
  • Dominating wind tunnel performance
  • Highest performing commercial carbon fiber
  • Branta C50 ULR 50mm 1230g Carbon Wheelset

or as low as $150/mo with

HSA/FSA eligible for qualified customers

Payment methods:

Select size See bicycle geometry

  • background email XS
  • background email S
  • background email M
  • background email L
  • background email XL

Size Guide

Not sure what size you should ride? Visit one of our dealers in your area. Find A Dealer

Delivery within 14 days

layer-mask

Size Chart

AD9

Frame Size Rider Height
XS 148 cm – 158 cm 4' 10" - 5' 2"
S 158 cm – 168 cm 5' 2" - 5' 6"
M 168 cm – 176 cm 5' 6" - 5' 9"
L 176 cm – 183 cm 5' 9" - 6' 0"
XL 183 cm – 191 cm 6' 0" - 6' 3"

AD9 Free Ground Shipping

Astana Team Edition Size: - Quantity: 1

$7,999
mask-layer

Notify Me

You have great taste – this bike sold out fast! If you want first dibs, drop your email and we’ll let you know as soon as it’s back in stock.

* When you ask to be notified, you are also subscribing to our newsletter for the latest product releases.

X-LAB AD9

The AD9 represents the pinnacle of X-LAB engineering. Designed in the wind tunnel and proven at the highest level of professional cycling, it is the official race machine of the XDS Astana WorldTour Team.

Every tube profile, surface transition, and structural element has been refined to minimize drag and maximize speed.

When the road opens up and the pace rises, the AD9 delivers what matters most: pure aerodynamic advantage, tested to the fullest by CFD and by wind tunnel.

This is the fastest road bike in the X-LAB lineup.

World-Class Aero Road Bike

Mount the race bike that has been proven time and time again by the XDS Astana, redefining what a WorldTour bike can do with a rare optimal combination of specs, geometry, and efficiency.

A Mastery of Carbon Fiber

Weighing just 6.8 kg with a Toray T1100 carbon frame, the AD9 leverages the best carbon build available from XDS’ decades of carbon mastery tested on championship-winning bikes.

Dominion over Wind Resistance

Using the latest engineering techniques of Computational Fluid Dynamics (CFD), the AD9 underwent strenuous wind tunnel testing in Silverstone that puts it firmly among the elites in aerodynamic race bikes.

Highlights AD9

  • Key Features

    Branta carbon crankset with integrated power meter + Apple Find My anti-theft technology

    Shimano Dura-Ace Di2 groupset

    Branta C50 ULR carbon wheelset with carbon spokes | 1,230 g

    XDS carbon frameset with Toray T1100 | Full bike 6.8kg

    prev
    next

    Branta carbon crankset with integrated power meter + Apple Find My anti-theft technology

    Shimano Dura-Ace Di2 groupset

    Branta C50 ULR carbon wheelset with carbon spokes | 1,230 g

    XDS carbon frameset with Toray T1100 | Full bike 6.8kg

  • Technical Specifications

    FRAME

    XDS Carbon Frame, Toray T-1100, UDH Compatible

    FORK

    XDS Carbon Fork, Toray T-1100, 100x12mm Thru-axle

    HANDLEBAR / STEM

    Branta Carbon Integrated

    SEATPOST

    XDS Carbon Seatpost, Aero Profile

    REAR DERAILLEUR

    Shimano Dura-Ace RD-R9250 Di2

    FRONT DERAILLEUR

    Shimano Dura-Ace FD-R9250 Di2

    SHIFTERS

    Shimano Dura-Ace ST-R9270 Di2

    BRAKES

    Shimano Dura-Ace BR-R9270

    CASSETTE

    Shimano Dura-Ace CS-R9200, 11-34T

    CRANKSET

    Branta Carbon Power Meter Crankset, 52-36T,

    29mm Alloy Spindle, Apple Find My Anti-Theft Technology

    BOTTOM BRACKET

    T47 29mm

    ROTORS

    Shimano SM-MT900, F:160mm R:140mm

    CHAIN

    Shimano CN-M9100

    WHEELSET

    Branta C50 ULR, Carbon Rims & Spokes, Ceramic Bearings

    TIRES

    Michelin Pro 5 700x28C

    Max Tire Clearance: 32C

    SADDLE

    Prologo Nago R4 PAS, Carbon Rails (Team Replica)

    Selle Italia SLR Boost, Carbon Rails (Hawkeye)

    WEIGHT

    6.82 kg / 15.03 lbs (Size L)

    SIZE OPTIONS

    XS / S / M / L / XL

  • product geometry anchor

    Geometry & Dimensions

    Basic geometry
    title XS S M L XL
    A — Seat Tube Length 470mm 495mm 515mm 540mm 565mm
    B — Top Tube Length 504mm 523mm 540mm 559mm 579mm
    C — Head Tube Length 105mm 118mm 130mm 148mm 171mm
    D — Seat Tube Angle 75° 75° 74° 74° 73°
    E — Head Tube Angle 71° 72° 73° 73° 73°
    F — Chainstay 410mm 410mm 410mm 410mm 410mm
    G — Wheelbase 970mm 978mm 982mm 992mm 1007mm
    H — Bottom Bracket Drop 72mm 72mm 70mm 70mm 70mm
    I — Stack in mm 505mm 520mm 534mm 553mm 575mm
    J — Reach in mm 371mm 379mm 387mm 395mm 405mm
    K — Front Center 575mm 582mm 583mm 592mm 607mm
    O — Stand Over 753mm 774mm 792mm 811mm 834mm
    • A — Seat Tube Length 470mm
      B — Top Tube Length 504mm
      C — Head Tube Length 105mm
      D — Seat Tube Angle 75°
      E — Head Tube Angle 71°
      F — Chainstay 410mm
      G — Wheelbase 970mm
      H — Bottom Bracket Drop 72mm
      I — Stack in mm 505mm
      J — Reach in mm 371mm
      K — Front Center 575mm
      O — Stand Over 753mm
    • A — Seat Tube Length 495mm
      B — Top Tube Length 523mm
      C — Head Tube Length 118mm
      D — Seat Tube Angle 75°
      E — Head Tube Angle 72°
      F — Chainstay 410mm
      G — Wheelbase 978mm
      H — Bottom Bracket Drop 72mm
      I — Stack in mm 520mm
      J — Reach in mm 379mm
      K — Front Center 582mm
      O — Stand Over 774mm
    • A — Seat Tube Length 515mm
      B — Top Tube Length 540mm
      C — Head Tube Length 130mm
      D — Seat Tube Angle 74°
      E — Head Tube Angle 73°
      F — Chainstay 410mm
      G — Wheelbase 982mm
      H — Bottom Bracket Drop 70mm
      I — Stack in mm 534mm
      J — Reach in mm 387mm
      K — Front Center 583mm
      O — Stand Over 792mm
    • A — Seat Tube Length 540mm
      B — Top Tube Length 559mm
      C — Head Tube Length 148mm
      D — Seat Tube Angle 74°
      E — Head Tube Angle 73°
      F — Chainstay 410mm
      G — Wheelbase 992mm
      H — Bottom Bracket Drop 70mm
      I — Stack in mm 553mm
      J — Reach in mm 395mm
      K — Front Center 592mm
      O — Stand Over 811mm
    • A — Seat Tube Length 565mm
      B — Top Tube Length 579mm
      C — Head Tube Length 171mm
      D — Seat Tube Angle 73°
      E — Head Tube Angle 73°
      F — Chainstay 410mm
      G — Wheelbase 1007mm
      H — Bottom Bracket Drop 70mm
      I — Stack in mm 575mm
      J — Reach in mm 405mm
      K — Front Center 607mm
      O — Stand Over 834mm
    Component geometry
    title XS S M L XL
    Fork Rate/Offset 48mm 48mm 43mm 43mm 43mm
    Trail 67mm 63mm 64mm 61mm 59mm
    Handlebar 360mm 360mm 380mm 380mm 400mm
    Stem 90mm 90mm 100mm 100mm 120mm
    Crankset 160mm 160mm 165mm 165mm 170mm
    Seat Post 300mm 300mm 350mm 350mm 350mm
    • Fork Rate/Offset 48mm
      Trail 67mm
      Handlebar 360mm
      Stem 90mm
      Crankset 160mm
      Seat Post 300mm
    • Fork Rate/Offset 48mm
      Trail 63mm
      Handlebar 360mm
      Stem 90mm
      Crankset 160mm
      Seat Post 300mm
    • Fork Rate/Offset 43mm
      Trail 64mm
      Handlebar 380mm
      Stem 100mm
      Crankset 165mm
      Seat Post 350mm
    • Fork Rate/Offset 43mm
      Trail 61mm
      Handlebar 380mm
      Stem 100mm
      Crankset 165mm
      Seat Post 350mm
    • Fork Rate/Offset 43mm
      Trail 59mm
      Handlebar 400mm
      Stem 120mm
      Crankset 170mm
      Seat Post 350mm

  • FAQ

    General

    What rider type is the AD9 designed for?

    AD9 is for a serious cycling enthusiast or racer, who knows exactly what components and race-ready frame geometry they’re looking for. This rider prioritizes watts and grams saved over everything else.

    Is the bike easy to assemble out of the box?

    Yes, AD9 is easy to assemble. You can refer to the written assembly guide or our assembly video to help guide you through the process. If you have any questions or doubts about assembling AD9 yourself, we recommend having it professionally assembled at your local bike shop.

    What’s the weight limit for the bike?

    AD9 has a weight limit of 220lbs (100kg), which includes the rider and any gear or cargo.

    Can the frameset be purchased separately?

    Yes, the AD9 frameset and other major components (including cockpit, crank, and wheels) are available for purchase.

    Where can my bike be serviced and repaired?

    Any local bike shop will be able to provide general service for your AD9. For any component customization or warranty issues we recommend going to an X-LAB dealer to receive the best expert guidance and support.

    Technical

    What is the maximum tire clearance?

    AD9 has clearance for up to 32c tires.

    Can the integrated power meter connect to third-party bike computers?

    Yes, the integrated power meter can connect to most major bike computers and fitness devices via ANT+. This allows live power data to be shared directly to your device. Live power data can also be shared via Bluetooth to the X-LAB Bikes app on your mobile device. At this time, live data can’t be shared to third party mobile apps via Bluetooth.

    Is the frame compatible with SRAM groupsets?

    Yes, the AD9 frame is compatible with most wired and wireless electronic groupsets from all major drivetrain brands.

    Does it use a UDH (Universal Derailleur Hanger)?

    Yes, AD9 uses a UDH.

    Is the aero cockpit compatible with standard bike computer mounts?

    Yes, the aero cockpit is compatible with standard 2-bolt under-handlebar bike computer and combo mounts. A basic bike computer mounting kit is also provided with the bike.

    What is the maximum chainring size supported?

    AD9 can fit up to 56-43T 2x front chainrings or a 68T 1x front chainring.

    Are other cockpit size options available?

    Yes, X-LAB has 18 different size options for the integrated aero cockpit on AD9.

    Are other crank length options available?

    Yes, X-LAB offers numerous crank length options for the Branta carbon power meter crankset for purchase.

    Are other chainring options available?

    Yes, X-LAB offers both compact (50-34T) and race (54-40T) front chainring options, in addition to the standard (52-36T) front chainrings that come stock on the bike. The X-LAB chainrings have a standard 110 BCD bolt pattern but feature a unique shape to integrate with the integrated power meter.

    Does the power meter measure left, right, or both sides?

    The Branta power meter crank is dual-sided, meaning it measures power from both left and right legs separately.

    Is the wheelset tubeless ready?

    Yes - the rims and tires on AD9 are tubeless ready and tubeless rim tape is already installed. Tubeless valves and sealant must be purchased separately.

  • Manual Downloads

  • Unboxing & Assembling

    AD9 Unboxing and Assembly
    AD9 Unboxing and Assembly
